Microscope 4 Dental

SCANER Calipso MD 500 | Fluorescence
Prijs: 19.500 EUR ex
Fluorescent Light Mode — Your Diagnostic Advantage
The fluorescent lighting mode enhances diagnostic precision by helping you:
-
Detect caries and hidden defects instantly
-
Differentiate natural tooth tissue from composite materials
-
Ensure complete removal of caries and restorative residues
Smart Light — Automatic Comfort
SCANER Calipso MD 500 Excellent features intelligent automatic light adjustment when magnification changes.
-
No blinding light at low magnification
-
Optimal brightness at high magnification
-
Seamless workflow without interruptions
Prefer manual control? It’s always available.
The “One Finger” Principle
The compact, perfectly balanced optical head allows full control with just one finger — without removing your eyes from the eyepieces or your hand from the handle.
Control includes:
-
Magnification adjustment from 3x to 24x
-
Vario lens working distance adjustment from 200–400 mm
-
Fine focus tuning
-
UV light activation and filter switching
Efficiency meets ergonomics.
Effortless Precision in Every Movement
The newly engineered tripod system with a powerful spring lever ensures ultra-smooth, controlled positioning of the optical head.
Enjoy:
-
Stable positioning
-
Fluid movement
-
Absolute control without physical strain
Exceptional Illumination & True Color Rendering
The advanced LED illuminator provides bright, natural light with an outstanding CRI of 94%, enabling accurate tissue evaluation and superior visual comfort.
Clean Design — No Distractions
All cables are hidden within the stand, maintaining:
-
Aesthetic elegance
-
Clinical safety
-
An organized workspace
Built-In Connectivity
Two integrated USB ports on the optical head arm allow you to:
-
Connect accessories
-
Charge devices during procedures
Everything you need — within reach.
Informative Smart Display
A dedicated display on the optical head shows:
-
Current magnification
-
Illuminator mode
-
LED temperature
Instant feedback. Complete control.
Hygiene & Protection
Designed for demanding clinical environments:
-
Sealed optical head
-
Passive LED cooling system
-
Silicone covers on control handles
Ensuring sterility, moisture resistance, and long-term reliability.
Quick-Change Filter System
Adapt instantly with integrated:
-
Green filter
-
Orange filter
-
Softening filter
Seamless transitions for any clinical task.
Functions | SCANER Calipso MD 500 | Configurations | Master | Excellent | Fluorescence |
|---|---|---|---|---|
Optics | High-quality German optics | ✔️ | ✔️ | ✔️ |
Eyepieces | Widefield eyepieces WF 12.5 x | ✔️ | ✔️ | ✔️ |
PD adjuster | Diopter adjustment range: ±6D, interpupillary distance adjustment range: 55 - 75 mm | ✔️ | ✔️ | ✔️ |
Binocular tube | Variable ± 90° ocular tilt angle | ✔️ | ✔️ | ✔️ |
Rotation ring | Binocular rotation ring | ✔️ | ✔️ | |
Optical dividers | 60° binocular adapter with one 20/80 optical channel divisor | ✔️ | ✔️ | ✔️ |
Magnification | Magnification: 5 steps 4× to 24× | ✔️ | ✔️ | ✔️ |
Smart Light | System of automatic regulation of illumination while changing magnification | ✔️ | ✔️ | |
Illuminance | Fanless high power LED ≥ 90.000 lux - High-CRI 94% - 6.500 K | ✔️ | ✔️ | ✔️ |
Filter | Orange & Green Filter | ✔️ | ✔️ | ✔️ |
LED Function Display | Indication: magnification values, "Smart Light", "Fluorescent Light" switching-on modes | ✔️ | ✔️ | ✔️ |
IP64 Protection | Protection against dust-tight and water splashes - optical head | ✔️ | ✔️ | ✔️ |
Power protection | Protection system of the power supply unit and the balancing lever against damages during their folding | ✔️ | ✔️ | ✔️ |
Caps | Set of sillicone caps | ✔️ | ✔️ | ✔️ |
Fluorescence Mode | Detect caries, hidden defects, distinguish between tooth tissue and composite material | ✔️ | ||
Fluorescence Filter | Protect the eyes, increase the contrast of the fluorescent image dimming | ✔️ | ||
One hand easy control | All functions can be operated with one hand | ✔️ | ✔️ | ✔️ |
Objective lenses | Objective lens f=200, 250, 300, 350 or 400 mm | |||
Vario objective | Variable objective lens f=200 - 400 mm | ✔️ | ✔️ | ✔️ |
Vario Lens | Protection glass | ✔️ | ✔️ | ✔️ |
Power cables | Integrated in microscope | ✔️ | ✔️ | ✔️ |
USB ports | 2 USB ports charging camera systems | ✔️ | ✔️ | ✔️ |
Connection | Micro HDMI connection | ✔️ | ✔️ | ✔️ |
Mount systems | Floor - Ceiling - Wall | ✔️ | ✔️ | ✔️ |
